本機是一種新型的實驗室磨礦設備。可供冶金、建材、化工、輕工、煤炭、水電、農業、地質、國防等部門實驗室作干濕兩用磨細某些忌鐵污染的礦石和其他物料之用。
Local laboratory is a new kind of grinding equipment. For metallurgy, building materials, chemicals, light industry, coal, hydropower, agriculture, geology, and other departments of national defense laboratory for wet and dry ground of dual-use some of the anti-pollution of iron ore and other materials.
| 型號規格 Model | 單位Uite | XMCQ-Ф180×200 | XMCQ-Ф280×290 | |
| 筒體尺寸 Drum size | mm | Ф180×200 | Ф280×290 | |
| 容積 Volume | L | 5.1 | 17．96 | |
| 筒體轉速 Drum speed | r/min | 116 | 70 | |
| 磨礦量 Capacity | kg | 0.25 | 3～5 | |
| 給料粒度 Feed size | mm | -2 | -2 | |
| 排料粒度 Outside size | mm | -0.074 | -0.074 | |
| 功率 Power | kw | 0.55 | 0.75 | |
| 磨礦瓷球規格 | Ф35(mm) | kg | 2.8 | 3.6 |
| Ф30(mm) | kg | 3.6 | 4.3 | |
| Ф25(mm) | kg | 5.6 | 6.5 | |
| 外形尺寸 Overall dimensions | mm | 1052×613×1160 | 700×570×1246 | |
| 質量 Weight | kg | 150 | 185 | |
注：瓷球數量可由用戶根據物料的性質和重量適當調整。
