·XY-1型鉆機 Core drilling rig

鉆機

XY-1型鉆機 Core drlling rig

XY-1型鉆機是一種具有油壓給進的輕便鉆機,適用于普查勘探、地球物理勘探、道路及建筑勘探以及打爆破孔等鉆進工程。不同的地層結構選用不同的合金、鋼砂及鋼粒等鉆頭可鉆進2-9級的砂質粘土及基巖層等。本機額定鉆孔深度100米,****開孔直經130mm經孔直經為75mm。

主要特點:

1、具有油壓自動給進機構,提高鉆進效率,減輕工人勞動強度。

2、采用球卡夾持機構代替卡盤,可實行不停鉆倒桿,操作方便,安全可靠。

3、配有孔底壓力計指示壓力,便于掌握孔內情況。

4、手柄集中,操作簡便。

5、結構緊湊,重量輕,適合于平原或山區工作。

6、重量輕、分解性強,便于搬遷。適合于平原或山區工作。

XY-1 drilling rig, as a portable rig with oil pressure feed  function, is applicable for drilling works like prospecting and exploration,  geophysical exploration, road & architectural exploration and blast hole  drilling etc. Different alloy, steel sand and particle drills can be used for  different stratum structures (e.g. levels 2-9 sandy clay and bedrock). The  rated drilling depth of this rig is 100m;  the minimum hole opening diameter is 130mm; the hole diameter is 75mm.

Key  Features:

1. Auto oil  pressure feed mechanism is provided to improve drilling efficiency and thus  reduce labor intensity.

2. The  easy-to-operate, reliable and safe ball-block holing mechanism that is used to  replace the chuck can realize rod placement during drilling.

3. Hole-bottom  pressure gauge is provided to indicate the pressure to facilitate the  understanding of situation inside the hole.

4. Handles are  concentrated for convenient operation.

5. Compact in  structure, light in weight, applicable to works in plain and mountain areas.

6. Light in  weight, high decomposability, portable, applicable to works in plain and  mountain areas.

鉆進深度 Drilling depthm100開孔直徑
Initial          hole dia.
mmФ110
終孔直徑 Initial hole dia.mmФ75鉆桿直徑Drill rod dia.mmФ42
鉆孔傾角 Angle range(°)90-75立軸轉速Spindle ration speedr/min142、285、570
立軸行程Spindle strokemm450****移動速度Maximum movement speedm/min3
****給進壓力Maximum feed pressurekN15水泵****排量Maximum pump outputL/min95
****許用壓力Maximum allowable pressureMpa1.2工作壓力Working pressureMpa0.7
柴油機(常柴)
Diesel          engine (Changchai)
ZS1100
額定功率 Rated Powerkw11額定轉速Rated speedr/min2200
電動機 MotorY132M-4型
額定功率
Rated          power
kw7.5額定轉速 Rated speed  Rated speedr/min1440
****起重量 Maximum lifting weightkN10提升速度Lifting speedm/s0.42、0.84、1.68
外形尺寸 Outside dimensionsmm1660×1030 ×1440重量 weightkg500k

XY-1型鉆機配套件

序號 №產品名稱 Description型號規格 Model
1鉆桿450
2鎖接頭465
3提引器465
4墊叉、板叉465
5自由鉗73/89
6巖心管Ф73
7巖心管Ф89
8巖心管接頭Ф75
9巖心管接頭Ф91
10變經接頭65/65
11主桿接頭42/50
12金剛石鉆頭Ф75
13金剛石鉆頭Ф91
14開孔管Ф89
15三角架客戶待定
